MC-IN60-2AB

Input	380VAC 50/60Hz, 53kW 82A
Output	150~500VDC 125A, 60kW
Temperature	-25~50℃
Humidity	≤95%
Charging Type	CCS1 + CHAdeMO(Adjustable)
UI	12.1 inch LCD touch display
IP	44
OS	Window 10
Payment	RFID / IC-CARD
Size(mm)	600(W) * 570(D) * 1,710(H)
Protection	Overvoltage, overcurrent, low voltage detection and charging blocking

MC-IN120-2AA

Input	380VAC 50/60Hz, 108kW 164A
Output	150~1,000VDC 200A, 120kW
Temperature	-25~50℃
Humidity	≤95%
Charging Type	CCS1 + CCS1(Adjustable)
UI	12.1 inch LCD touch display
IP	44
OS	Window 10
Payment	RFID / IC-CARD
Size(mm)	720(W) * 600(D) * 1,710(H)
Protection	Overvoltage, overcurrent, low voltage detection and charging blocking
